TEP duct flanged temperature sensor
Produal TEP
TEP sensors are designed to measure temperature in pipes with adjustable flange mounting.
The TEP temperature sensor is designed for automatic HVAC systems to detect radiator temperatures. Temperature is detected using the most common sensors available on the market. The housing is made of heat-resistant plastic. The sleeve and terminal blocks are angled at 45° for easy installation. The sensor is mounted on the pipe using an adjustable clamp.
Measurement/s
Temperature
Units of measurement
ºC
Measuring range
-50...70 °C
Accuracy / Resolution
±0,2 a 0,5 °C
Output signal
Resistance
Power supply
15…35 Vdc (Model -LL) ; 24 Vac/dc, < 1 VA (Models -LU y -M)
Environmental protection
IP54
IP protection class notes
Rear sheath and stuffing box at the bottom
Housing / Materials / Connections
PBT, PC, PA, stainless steel
Dimensions
Sonda Ø 8 x 200 mm
Mounting / Installation
With flange
TEP-PT100
100 Ω (0 °C), accuracy ±0.3 °C (0 °C), EN 60751/B
TEP-PT1000
1000 Ω (0 °C), accuracy ±0.3 °C (0 °C), (Honeywell, Danfoss equivalent)
TEP-NTC 10
10 kΩ (25 °C), accuracy ±0.2 °C (25 °C) (Trend, Distech equivalent)
TEP-NTC 20
20 kΩ (25 °C), accuracy ±0.2 °C (25 °C) (Honeywell equivalent)
TEP-NI 1000
1000 Ω (0 °C), accuracy ±0.4 °C (0 °C), (Sauter equivalent)
TEP-NI 1000-LG
1000 Ω (0 °C), accuracy ±0.4 °C (0 °C), (Siemens equivalent)
TEP-NTC 10-KB
5025 Ω (25 °C), accuracy ±0.5 °C (25 °C)
TEP-NTC 1.8
1800 Ω (25 °C), accuracy ±0.3 °C (25 °C), (TAC, Schneider equivalent)
TEP-NTC 10-AN
10 kΩ (25 °C), accuracy ±0.25 °C (25 °C) (equivalent to Schneider, Andover)
TEP-KP 10
LM235Z, 10 mV/K, 2,98 V / 25 °C
TEP-NTC 10-C
10 kΩ (25 °C), accuracy ±0.25 °C (25 °C) (Carel equivalent)
TEP-T1
2226 Ω (0 °C), accuracy ±0.4 °C (0 °C)
